40KW Induction Heating Machine Electric Magnetic Power Supply For Cast Iron Melting

Induction heating machine 40KW For cast iron melting electric magnetic power supply

CR1300 series intelligent induction heating power supply is a series of products designed based on the combination

of modern industrial design thought and future industrial intelligent idea. The product adopts efficient air-cooled structure

design, IGBT full-bridge inverter topology, phase shift PWM control technology, automatic current frequency tracking,

the output power is 0~100% poleless adjustable.
CR1300 series is mainly used in all kinds of plastic machinery (such as: injection molding machine, extruder, pelletizer,

film blowing machine, wire drawing machine energy-saving transformation), chemical fiber equipment, food and medicine

machinery, steam and hot air preparation and other industries.

Quick Detail Induction heating machine 40KW For cast iron melting electric magnetic power supply

Place of Origin:China (Mainland)

Brand Name:Canroon

Model Number:CR1300-040A

Power : 40kw

Voltage : 3-phase 380-460V

startup time :< 0.2S

Electro-thermal conversion : > 95%

Effective power :> 85%

Usage : Industrial Heat System

Storage temperature :-30℃～+60℃

Overload protection :120% per minute 150% instant protection

Certification:CE ISO9001:2015

Main functions of  Induction heating machine 40KW For cast iron melting electric magnetic power supply

Various heating modes
Maximum power heating, curve heating, twenty section heating, analog amount (0 ~ 10V /4 ~ 20mA) control

heating and other heating modes

Twenty stage heating mode:
Set the heating mode (F008) to 0, that is, set the 20-stage heating mode. The heating power and heating

time length (F063 ~ F102) of each section of the 20 sections can be set to run in accordance with the

predetermined heating curve mode. In the process of operation, the section with zero power can be

skipped, and the power rise and fall rate can be set to improve the operating efficiency.

The 20-stage heating mode can set the heating time and power of the curve in each stage. The running time

of the power in the N-stage is the heating time of the N-stage. After the end of the 20 stages, the heating power

of the last stage is used for heating. The 20-section curve heating model is shown in the figure below:

Enterprise introduction Induction heating machine 40KW For cast iron melting electric magnetic power supply

Canroon is a remarkable energy saving solutions provider,whose products and solutions are widely used

in shipbuilding, aviation, automotive, metallurgy, chemical engineering, petroleum pipeline construction,

new materials, new energy and other fields.
Canroon has a professional R & D team, committed to convert its wisdom into leading products and services

to meet the needs of different customers, continuing to create values for customers.
Canroon has been striving to promote the sustainable and healthy development of China's energy conservation

and emissions reduction career, with comprehensive advantages in the field of power electronics.We aim to

become the industry leader and our duty is to improve the earth's.

Technical parameters of Induction heating machine 40KW For cast iron melting electric magnetic power supply

Application details of Induction heating machine 40KW For cast iron melting electric magnetic power supply

Company information Induction heating machine 40KW For cast iron melting electric magnetic power supply:

Our Services Induction heating machine 40KW For cast iron melting electric magnetic power supply

1. keep the quality first and make more products benefit to our customers' need

2.about our Online/Sale service

super and solid quality,Fast and punctual delivery,Standard export package or as customers’ need.

3.After-sale service

Assistance to your project,Repairing and maintenance if any problem occur in the warranty, Installation and

clerks training,Spare and wearing parts for free or with big discount,Any feedback of machines can be told to

us, and we will try our best to support you.

FAQ Induction heating machine 40KW For cast iron melting electric magnetic power supply:

1. Are you a trading company or manufacturer?

We are manufacturer located in Shenzhen, China, specialized in induction heating power for many years.

2. What's the delivery time for sample and bulk order?

Normally we have stock of the mini and medium items, 1-3 days for sample order, 15-40days for 20 GP and 40HQ quantity.

3. What's your quality guarantee period?

12 months warranty

4. Can I get a lower price if I order large quantities?

Of course. Cheaper price with larger quantity

5. can you customize the machine for us?

Yes, of course, just tell me your detailed requirement, so I can suggest you most suitable project.
