160KVA Induction Heat Treatment Machine ISO Certificate With Advanced System
Product Details
| Input | 6 Channel TC Input | Product Model | CR2000-160B-14TF |
|---|---|---|---|
| Output Frequency | 2.5-35KHz | Input Current | 192-288A |
| Input Power | 160KVA | Output Power | 145kW(duty Cycle 100%) |
| Temperature Rating Operation | -20C~+50C | Certificate | CE ISO9001 |
| Application | >90% | Dimension | W: 596mm H: 1252mm D: 805mm |
| High Light | 160KVA Induction Heat Treatment Machine,Induction Heat Treatment Machine ISO,6 Channel Induction Heat Treatment Machine |
||
Product Description
160KVA Induction Heating Power Supply Advanced System Integration
Product Description:
Induction Heating Power Supply is a high-performance and advanced system integration product designed to meet the needs of PWHT (Post Weld Heat Treatment). The product model is CR2000-160B-14TF with an input of 6 Channel TC Input. The efficiency of the product is over 90%, and it has a wide range of inductance from 3-500uH with a protection level of IP20. Moreover, the product is highly customizable to meet the specific needs of the customer.
Features:
- Product Name: Induction Heating Power Supply, can be customized.
- Temperature rating Operation: -20C~+50C, suitable for preheat in extreme cold outdoors.
- Input: 6 Channel TC Input.
- Efficiency: >90%, high efficiency.
- Output Frequency: 2.5-35KHz.
- Relative Humidity: ≤90%.
Technical Parameters:
| Product Feature | Specification |
|---|---|
| Input Current | 192-288A |
| Temperature rating Operation | -20C~+50C |
| Dimension | W: 596mm H: 1252mm D: 805mm |
| Inductance Range | 3-500uH |
| Input Frequency | 50-60Hz |
| Output Power | 145kW(duty Cycle 100%) |
| Output Frequency | 2.5-35KHz |
| Input Power | 160KVA |
| Input Voltage | 3-phase 380-460V |
| Input | 6 Channel TC Input |
| Application | Preheat in extreme cold outdoors, can be customized |
Applications:
Induction Heating Power Supply - Canroon CR2000
Canroon CR2000 Induction Heating Power Supply is a CE certificated large power device that offers advanced system integration for a wide range of industrial applications. With its input power of 160KVA, input current of 192-288A, input voltage of 3-phase 380-460V, and input frequency of 50-60Hz, this device is IP20 rated and is perfect for any large scale production needs. Moreover, the Canroon CR2000 Induction Heating Power Supply can be customized to meet the specific requirements of your business.
The Canroon CR2000 Induction Heating Power Supply is available at a negotiated price and comes with a minimum order quantity of one. It is packaged in a wooden box and typically delivered within 7-15 days. Payment terms include L/C, T/T, Western Union, and Paypal. We can supply up to 300 pieces per week.
Customization:
Induction Heating Power Supply
Brand Name: Canroon
Model Number: CR2000
Place of Origin: Shenzhen, China
Certification: CE ISO9001
Minimum Order Quantity: 1
Price: negotiated price
Packaging Details: wooden box
Delivery Time: 7-15 days
Payment Terms: L/C, T/T, Western Union,Paypal
Supply Ability: 300 Piece/Pieces per Week
Input Frequency : 50-60Hz
Input Current: 192-288A
Input Voltage: 3-phase 380-460V
Temperature rating Operation: -20C~+50C
Output Frequency : 2.5-35KHz
Features
- Ideal for metal heat treatment
- High efficiency
- Precise temperature control
- Induction Heating Power Supply
Support and Services:
Induction Heating Power Supply Technical Support and Service
At XYZ, we are proud to provide the highest quality technical support and service for our induction heating power supply products. We understand that our customers expect reliable and efficient products that provide consistent and reliable performance.
We are always available to answer any questions that you may have about our products and services. Our technical team is available 24/7 to provide technical assistance and support. We also offer a wide range of maintenance and repair services for our induction heating power supply products.
We also provide warranty services for our products. Our warranty covers any defects or malfunctions that may occur as a result of our manufacturing process. We also provide extended warranties for our products, to ensure that our customers are covered in the event of an unexpected malfunction.
If you have any questions or need assistance with your induction heating power supply, please do not hesitate to contact us. We are always here to help.
FAQ:
- Q: What is the brand name of the Induction Heating Power Supply?
- A: The brand name of the Induction Heating Power Supply is Canroon.
- Q: What is the model number of the Induction Heating Power Supply?
- A: The model number of the Induction Heating Power Supply is CR2000.
- Q: Where is the place of origin of the Induction Heating Power Supply?
- A: The place of origin of the Induction Heating Power Supply is Shenzhen, China.
- Q: What are the certifications of the Induction Heating Power Supply?
- A: The certifications of the Induction Heating Power Supply are CE ISO9001.
- Q: What is the minimum order quantity of the Induction Heating Power Supply?
- A: The minimum order quantity of the Induction Heating Power Supply is 1.
- Q: What is the price of the Induction Heating Power Supply?
- A: The price of the Induction Heating Power Supply is negotiatable.
- Q: How will the Induction Heating Power Supply be packaged?
- A: The Induction Heating Power Supply will be packaged in a wooden box.
- Q: How long will the delivery take for the Induction Heating Power Supply?
- A: The delivery time for the Induction Heating Power Supply is 7-15 days.
- Q: What are the payment terms for the Induction Heating Power Supply?
- A: The payment terms for the Induction Heating Power Supply are L/C, T/T, Western Union, and Paypal.
- Q: What is the supply ability of the Induction Heating Power Supply?
- A: The supply ability of the Induction Heating Power Supply is 300 pieces per week.
Shipping ways
1. Fedex/DHL/UPS/TNT for samples, door to door;
2. By air or by sea for batch goods for FCL, airport/port receving;
3. Customers specifying freight forwarders for negotiable shipping nethods.
4. Delivery time: 3~7 days for samples, 10~25days for bulk order goods.
